Variants
To meet diverse application needs, our cylinders are available as:
- Single or double acting
- Diaphragm
- Cable traction
- Telescopic
- Tandem continuous double
- Pneumatic or hydraulic cushioned
Technical Specifications
Standard and special cylinders per NFPA and JIC recommendations.
- Nominal pressure: 180 kg/cm²
- Max working pressure: 210 bar
- Stroke tolerance:
- 0–1000 mm: ±1 mm
- ≥1000 mm: ±2 mm
- Max speed: 0.5 m/s
- Fluid: mineral oil
- Temp range: -20° to 80°C
- Viscosity: 2.8 to 380 mm/s
Special executions:
- Interior hard chrome barrel protection
- Rod bellows
Features
Configured to your mounting, cushioning, accessory and stroke requirements.
- SAE 1010 steel head
- Seamless steel barrel, 10 micro‑inch finish
- SAE 64 bronze bushing
- Polipak seals
- SAE 1045 rod (4140 optional) with 50 μm hard chrome
- Yield limit: 3260 kg/cm²
- Hardness: HRC 68
- Roughness: 0.1 μm
- SAE 1045 piston with SAE 64 bronze anti‑friction guide (≤ ∅ 2″)
